Universal Laser Systems X-660

Questions and Answers

C
carrie81Aug 17, 2025
What to do if raster engraving appears sharp on both ends but fuzzy in the middle on Universal Laser Systems X-660?
- A
  Amber JonesAug 17, 2025
  If you notice that the raster engraving appears sharp on both ends but fuzzy in the middle on your Universal Laser Systems Cutter, it could be due to several reasons: * The laser system might be dirty. Clean all optics, rails, bearings, and belts. * Something might be loose. Check the X-axis bearings, drive gear, idler pulley, belt, and optics. * The system may need tuning. Run the “Tuning” feature in the printer driver. * The X-axis belt and/or drive gear might be worn. Replace the belt and/or drive gear and run the “Tuning” feature. * The laser tube might be faulty. Replace the laser tube.
F
Faith RussellAug 28, 2025
Why fine detail is missing when raster engraving on Universal Laser Systems X-660 Cutter?
- C
  Christopher OlsonAug 28, 2025
  If you're missing fine details like serifs or thin lines when raster engraving with your Universal Laser Systems Cutter, it might be due to: * The speed being too fast for the material. Try slowing down the engraving speed. * The laser not responding to low duty-cycle, high-speed engraving. Run the enhancement feature in the printer driver. * The system being out of focus. Refocus. * The system needing tuning. Run the “Tuning” feature in the printer driver. * The laser spot size being too big. Use a shorter focal length lens.
J
Justin AndersonSep 1, 2025
Why vertical or diagonal background pattern appears when raster engraving on Universal Laser Systems X-660?
- A
  Alicia MahoneySep 1, 2025
  If you observe a vertical or diagonal background pattern while raster engraving large areas or amounts of material with your Universal Laser Systems Cutter, it could be due to: * A dirty laser system. Clean all optics, rails, bearings and belts. * Loose motion system components. Check the X-axis bearings, belt, and optics. * Worn or damaged X-axis bearings. Replace the X-axis bearings. * Worn or damaged X-axis rail. Replace the X-axis arm.
M
michaelmccoySep 5, 2025
Why horizontal background pattern appears when raster engraving on Universal Laser Systems Cutter?
- C
  crystal56Sep 5, 2025
  If a horizontal background pattern appears when raster engraving large areas or amounts of material on your Universal Laser Systems Cutter, it could be caused by: * A dirty laser system. Clean all optics, rails, bearings and belts. * The laser being too cold or hot. Ensure the ambient temperature is within specifications. * A faulty laser tube. Replace the laser tube.
X
xyangSep 8, 2025
Why engraving appears “halftoned” when using colors other than black on Universal Laser Systems X-660?
- S
  Sharon Clark PhDSep 9, 2025
  If the engraving appears “halftoned” and not solidly filled when using colors other than black on your Universal Laser Systems Cutter, it may be because the graphics, graphic software, graphic software setup, color palette, monitor display colors, or driver settings have changed. Check to see what has changed and refer to the “Computerized Controls” manual to properly set up the graphics software. Also, check the driver settings.
S
Sheila RojasNov 13, 2025
Why engraving does not appear as deep as it normally does in Universal Laser Systems X-660 Cutter?
- S
  Sarah ClarkNov 13, 2025
  If the engraving does not appear as deep as it normally does on your Universal Laser Systems Cutter, consider the following potential causes and solutions: * A change in graphics, graphic software, graphic software setup, color palette, monitor display colors, or driver settings. Check what has changed and use the Software Setup Guide to properly set up the graphics software and check driver settings. * The system might be out of focus, so refocus it. * The material or its density may have changed, so check the material. * Settings may have been altered, so check power, speed, PPI, and DPI settings. * The laser system might be dirty; clean all optics, rails, bearings, and belts. * Laser tube cooling fan filters might be dirty; check and clean them. * Ambient temperature migh...
J
James CalhounNov 20, 2025
Why raster engraving or small text appears like a double image on Universal Laser Systems Cutter?
- S
  sara96Nov 20, 2025
  If the raster engraving or small text appears as a double image on your Universal Laser Systems Cutter, consider the following: * The laser system may be dirty. Clean all optics, rails, bearings, and belts. * Changes may have occurred in the graphic, graphic software, graphic software setup, color palette, monitor display colors, or driver settings. Check what has changed and refer to the “Computerized Controls” manual to properly set up the graphics software. Check driver settings. * The speed may be too fast for the material. Slow down the engraving speed. * The system may be out of focus. Refocus. * The system may need tuning. Run the “Tuning” feature in the printer driver. * The X-axis belt and/or drive gear may be worn. Replace the belt and/or drive gear and run the “Tuni...
R
reeserobertNov 23, 2025
What to do if engraving is sharp on one side and fuzzy on the opposite side on Universal Laser Systems X-660?
- J
  jaimerobertsNov 23, 2025
  If your engraving is sharp, clear, and at a good depth on one side of the table but fuzzy and shallow on the opposite side with your Universal Laser Systems Cutter, here's what you can check: * The system may be out of focus, so refocus. * The laser system may be dirty, so clean all optics, rails, bearings, and belts. * The material may not be level or may vary in thickness. Check the focus point of the material in different places and adjust the height by shimming the material or using more thickness-consistent material. * The table may not be level. Using the focus tool, focus directly on the surface of the table in all four corners. The table should be within +/- .020 inches from one corner to the other. Adjust if necessary. * The laser beam may be out of alignment with the o...

Summary

Introduction

How To Get Help

Steps for contacting technical support and troubleshooting guidance.

Specifications

System Operating Environment Requirements

Specifies the environmental conditions for safe and optimal system operation.

System Specifications

Details the technical specifications of the laser system, including dimensions and power.

Safety

Description of Appropriate Use

Defines the intended applications and limitations of the laser system.

General Safety

Outlines crucial safety precautions for operating the laser system.

Laser Safety

Details hazards and precautions related to laser beam exposure and interlocks.

EU Compliance (CE)

Information regarding European Union conformity standards and directives.

FCC Compliance

Information regarding Federal Communications Commission compliance for radio frequency emissions.

Recycling

Information on the proper recycling of electronic components and the system.

Installation

System Operating Requirements

Outlines environmental and electrical requirements for proper system installation.

Exhaust System (user supplied)

Details requirements for the exhaust system installation and airflow.

Minimum PC Computer Configuration

Specifies the minimum computer hardware requirements for system operation.

Suggested Software (user supplied)

Lists recommended graphics and scanning software for system use.

System Assembly

Step-by-step instructions for assembling the laser system components.

Leveling the System

Procedure for adjusting the system's casters to ensure it is level.

Laser Cartridge Installation

Step-by-step guide for installing the laser cartridges into the system.

Checking Beam Alignment

Procedure to verify and adjust the laser beam's alignment for optimal performance.

Finalizing the Connections

Steps to complete system connections, including exhaust and computer interface.

Printer Driver Installation

Instructions for installing the necessary printer drivers for system operation.

System Operation

The Control Panel

Overview of the laser system's control panel, buttons, and status indicators.

Menu System

Explanation of the system's menu structure, navigation, and display modes.

System Memory, Preferences, and Options

Covers managing memory, system preferences, and optional features.

System Settings and Modes

Details on setting focus, rotary axis, language, units, and diagnostic modes.

Origin Position and Focusing Methods

How to set origin position and an overview of focusing methods.

Focus Tool Method

Step-by-step guide on using the focus tool for precise laser focusing.

Material Thickness and Autofocus Methods

Using Z-axis for material thickness focusing and the autofocus feature.

Making a Sample, Step-by-Step

A practical walk-through for creating a sample engraved and cut item.

Process Initiation and Completion

Steps to start engraving, stop, and safely remove processed materials.

System Component Overview

Explanation of the laser system's core components and their functions.

Motion System

Details the mechanical parts of the laser system and their movement.

Laser Beam Modes

Describes single beam and dual beam operation modes for different laser configurations.

Basic Maintenance

Motion System Components Diagram

Identifies all components of the laser system's motion system for maintenance reference.

Cleaning and Maintenance Supplies

Lists all necessary supplies for effective cleaning and maintenance.

System Cleaning and Maintenance

Procedures for cleaning the motion system, optics, and enclosure.

Optics Cleaning

Detailed instructions for cleaning mirrors, focus lens, and beam window.

Exhaust and Filter Maintenance

Procedures for cleaning exhaust plenum and cooling fan filters.

Adjustments, Lubrication, and Schedule

Information on system adjustments, lubrication, and recommended maintenance tasks.

Troubleshooting Guide

Common problems and their solutions for engraving quality and operation.

Material Settings Guide

Safety

Critical safety warnings and precautions related to material processing.

Printer Driver Setting Tips

Guidance on adjusting power, speed, and PPI for optimal results.

Acrylic - Cast and Extruded Settings

Recommended laser settings for engraving and cutting cast and extruded acrylic.

Anodized Aluminum Settings

Recommended laser settings for engraving anodized aluminum.

Leather Settings

Recommended laser settings for engraving and cutting leather.

Wood Settings

Recommended laser settings for engraving and cutting wood.

Rubber Stamps Settings

Recommended laser settings for engraving and cutting rubber stamps.

Sign Vinyl Settings

Recommended laser settings for engraving and cutting sign vinyl.

Accessories

Air Assist System

Information on the Air Assist system, its purpose, and operational styles.

Air Assist Connections, Control, and Maintenance

Instructions for connecting, controlling, and maintaining the air assist system.

Dual Head Accessory

Information about the Dual Head accessory for increased engraving productivity.

Honeycomb Cutting Table

Instructions for installing the honeycomb cutting table onto the engraving table.

Focus Lens Kits

Information on optional focus lens kits and their specifications.

Rotary Fixture

Instructions for installing, operating, and removing the rotary fixture for cylindrical engraving.
