Extreme Hoops operation manual
13
3.2 Control Pane Layout
.
link1
link2
Connect the wires to
the PCB as per the
numbers marked on
the PCB.
High voltage exit
Low voltage exit
Link wire “Link1”
exit
Power cord exit
Link wire “Link2”
exit
Low voltage
wires go
through this
hole
High voltage
wires go
through this
hole
Power cord exit
