Universal Space Extreme Hoops - Bracket

Extreme Hoops operation manual
31
No.
Part No.
Name
Material
Spec.
Qty.
1
E-101-431-000
Guide
Q235
d 1.5 White
1
2
E-101-432-000
Cross recessed pan head
screw kit
Q235
M4x10 color zinc
13
3
E-101-600-000
Cover
Clear PVC
d 1
1
4
E-101-433-000
Cross recess pan head
bolt kit
Q235
M8x45 color zinc
12
5
E-101-434-000
Non-metallic hexagon
lock nut
M8
112
6
E-101-502-000
Low speaker
Plywood
d 15
1
7
E-101-435-000
Cross recessed pan head
screw kit
Q235
M4x25 color zinc
12
8
E-101-102-000
Ticket box243243
Q235
d 1 White
1
9
E-101-002-000
Control panel assy
1
10
E-101-436-000
Cross recessed pan head
screw kit
Q235
M8x25 color zinc
4
11
E-101-006-000
Speaker
1 Left & 1Right
12
E-101-007-000
Side-front bracket assy
1 Left & 1Right
13
E-101-704-000
Control Panel Assy
Clear plastic
d 5 Silkscreen
1
14
E-101-437-000
Hexagon flat round head
screws
Q235
M4 x16 nickel
plating
13
15
E-101-601-000
Control panel plastic
Melon white
plastic&5
1
16
E-101-503-000
Playfield 1
Plywood
d 15 Paste royal
blue rubber board
1
17
E-101-438-000
Hexagon flat head
screw
Q235
M8x25 nickel
plating
27
18
E-101-008-000
Side middle bracket assy
2
19
E-101-009-000
Side back bracket assy
2
20
E-101-010-000
Side upper bracket assy
2
21
E-101-102-000
Top net board
Q235Wire
mesh
d 2 White
1
22
E-101-103-000
Control panel lock
Q235
White zinc
2
23
E-101-105-000
Coin mech. lock
Q235
White zinc
1
24
E-101-439-000
Lock
2222
1
25
E-101-106-000
Coin door lock
Q235
White zinc
2
26
E-101-440-000
Lock
171
4
