Universal Space Extreme Hoops - Disassembly

Extreme Hoops operation manual
19
5. DISASSEMBLY
If you need to move the game in short distance, adjust the levelers back to an “up” position so
the casters touch the ground. If you need to move the game in long distance, it is highly
suggested that you disassemble the game before transporting, and reassemble later. To
disassemble the game, follow the steps described below:
 To remove the control panel:
Step 2: Unplug the high voltage and low
voltage connectors as shown.
Step 4: Remove screws on the two sides of
the control panel.
Step 3: Disconnect the wires in the middle
hole carefully. Do not break the wire.
Step 1: Unplug the connectors from the
PCB
