Extreme Hoops operation manual
37
NO
PART NO
NAME
QTY
SPEC
Material
1
E-101-508-000
Playfield2
1
δ15Paste royal blue
rubber board
Playfield
2
2
E-101-118-000
Ball gate fixe board
1
δ2 White
Q235
3
E-101-475-000
Cross recess hexagon
bolt kit
20
M6×16 color zinc
Q235
4
E-101-607-000
Ball gate axle sleeve
2
Copper powder
5
E-101-476-000
Shield ring
2
d
0
=15
6
E-101-477-000
AC reducing motor
1
YA60-6Z/60JB100J8
220V
7
E-101-478-000
Cross recessed pan
head screw kit
4
M5×12 color zinc
Q235
8
E-101-119-000
Hinge
1
δ1.5 color zinc
plating
Q235
9
E-101-479-000
Cross recessed pan
head screw kit
11
M4×16 color zinc
Q235
10
E-101-480-000
Encoder wheel
1
Electrophoresis black
Q235
11
E-101-481-000
Hexagon socket set
screw
2
M4×16
Q235
12
E-101-482-000
Non-metallic hexagon
lock nut
11
M4
13
E-101-483-000
Ball gate connector
1
δ3
Stainless
steel
14
E-101-484-000
Ball gate sensor board
1
δ5 White
Q235
15
E-101-485-000
Cross recessed pan
head screw kit
2
M4×10 color zinc
Q235
16
E-101-120-000
Ball gate
1
δ2 White
Q235
17
E-101-121-000
Ball gate motor
bracket
1
δ2 White
Q235
18
E-101-122-000
Ball gate motor cover
1
δ1 White
Q235
19
E-101-486-000
Sensor
1
