Extreme Hoops operation manual
39
NO
PART NO.
NAME
QTY
SPEC
1
E-101-487-000
Button
2
60# White round flat
button
2
E-101-488-000
Bulb
4
12V 3W
3
E-101-489-000
Micro SW
2
Yellow
4
E-101-490-000
Coin mech.
2
CEC
5
E-101-491-000
Coin SW
2
ZIPPYCNR-055-03-Z
6
E-101-492-000
Bulb clamp
2
Coin lamp
7
E-101-493-000
Power cord
1
3．5M
8
E-101-494-000
Counter
1
12V
9
E-101-495-000
Test button
3
Red black and green
for each one
10
E-101-496-000
Dual POT
1
1K
11
E-101-497-000
Single POT
1
10K
12
E-101-123-000
Coin box
1
13
E-101-498-000
Coin box door lock
1
14
E-101-801-000
Relay board
1
JDQ-LY2J-12V
15
E-101-802-000
Main board
1
V8
16
E-101-499-000
Service door lock
1
GU071
17
E-101-124-000
Ticket box
1
Q235
18
E-101-803-000
Ticket conversion
board
1
TICK-CH.PCB
19
E-101-4100-000
Ticket mech.
1
TD-963CR
20
E-101-4101-000
Ticket lock
1
GU071
21
E-101-4102-000
Power box
1
EPM-S-250D12+24
22
E-101-4103-000
Power switch
1
12A/125V 1/4HP
23
E-101-4104-000
Fuse
1
10A/125V φ5-20
24
E-101-4105-000
Fuse socket
1
10A/250V R3-11
25
E-101-4106-000
Filter
1
10GENG3E-R
26
E-101-4107-000
Amplifier box
1
27
E-101-4108-000
Sound box hole
1
28
E-101-4109-000
10” Speaker
1
80-150W 10”
29
E-101-4110-000
Speaker door lock
1
GU071
