Extreme Hoops operation manual
43
NO
PART NO.
NAME
SPEC
MATERIAL
QTY
1
E-101-704-000
Front side-L
decal
418×512
PVC100U glue
1
2
E-101-705-000
Middle side-L
decal
698×512
PVC100U glue
1
3
E-101-706-000
Rear side-R
decal
698×698
PVC100U glue
1
4
E-101-707-000
Button
decal(link)
50×50
PVC100U glue
1
5
E-101-708-000
Front door decal
PVC100U glue
1
6
E-101-709-000
Ticket decal
66×20
PVC100U glue
1
7
E-101-710-000
Button (decal
single)
50×50
PVC100U glue
1
8
E-101-711-000
Play method
120×70
PVC100U glue
1
9
E-101-712-000
Control panel
decal
1006×306
silkscreen
d5 Plastic
1
10
E-101-713-000
Front side-R
decal
418×512
PVC100U glue
1
11
E-101-714-000
Middle side-R
decal
698×512
PVC100U glue
1
12
E-101-715-000
Rear side-R
decal
698×698
PVC100U glue
1
13
E-101-716-000
Main interface
upper
930×407
silkscreen
d5 Plastic
12
14
E-101-717-000
Main interface
down
930×830
silkscreen
d5 Plastic
1
15
E-101-718-000
Baffle decal
645×150
PVC100U glue
1
16
E-101-719-000
No touching
decal
66×66
PVC100U glue
1
17
E-101-720-000
Ball gate motor
cover decal
97×70
PVC100U glue
1
18
E-101-721-000
Wire screw
instruction
sticker decal
360×361
PVC100U glue
1
19
E-101-721-000
Forklift note
sticker
180×269
PVC100U glue
1
20
E-101-125-000
Chinese 220V
Nameplate
97×70
d 0.5 Aluminum
plate
1
21
E-101-722-000
220V Power
stickers decal
97×70
PVC100U glue
1
22
E-101-721-000
High voltage
decal
41×42
PVC100U glue
1
