Lane Master Manual
07/19/2017
15
4.4.3 Connect Lane Assembly & Display Assembly
No. Part No. Code No. Name Picture Qty
1 L105-125-000 20101048028
Hexagon flat round head
screws
16
2 L105-144-000 20113040051 C flat washer 16
Place the Lane in front of the dis
p
la
y
assembl
y
and install as shown.
Connect the Lane Assembly and
Display Assembly with screws and
washers.
P1
One side 8 pcs
