Universal E-40 - Hardware; Tools

8
HARDWARE / TOOLS
Tools
Included Not Included
4 mm
5 mm
(recommended)
Item Qty Description Item Qty Description
A 6 FlatHeadHexScrew,M8x20 J 2 Sleeve, Plastic
B 18 ButtonHeadHexScrew,M8x15 K 6 FlatWasher,M6
C 6 Washer, Curved L 6 ButtonHeadHexScrew,M6x12
D 18 Spring Washer, M8 M 2 Shaft
E 4 Flat Washer, Wide N 2 Pedal Mount Plate
F 4 PlasticWasher(D16.2) O 8 Flat Washer, M8
G 2 WaveWasher,Small(D16.5) P 4 CarriageBolt,M6x25
H 2 Washer Q 4 ButtonHeadHexScrew,M6x14
I 2 Wave Washer, Large (D20)
Note: Select pieces of Hardware have been provided as spares on the Hardware Card. Be aware that there may
be remaining Hardware after the proper assembly of your machine.
6 mm/#2 (2)
