Universal U-15 - Parts

7
PARTS
Item Qty Description Item Qty Description
1 1 Main Frame 8 1 Console
2 1 Front Stabilizer 9 1 Handlebars
3 1 Rear Stabilizer 10 1 Left Pedal (L)
4 1 Seat Post 11 1 Right Pedal (R)
5 1 AdjustmentKnob(pre-installed) 12 1 Water Bottle Holder
6 1 Seat 13 1 Media Tray
7 1 ConsoleMast(withpre-installedHandlebar
Bracket)
Note: Media Cable is attached to the Console.
1
5
8
9
6
2
3
4
10 (L)
11 (R)
12
7
13
