32
If the chosen location does not have a suitable support beam
capable of supporting 45Kg, install a 2"x4" support between
the roof beams as a support medium.
Make sure that the bracket for hanging the fan to the ceiling
or other suitable structure is capable of supporting at least
45Kg, with the two long fixing screws included. Make sure
that at least 30 mm of the screw is screwed into the bracket.
Only the fans with a support rod or bar can be installed on sloping
roofs where the angle of inclination does not exceed 25º. This
model cannot be installed on sloping roofs.
Our fans are not designed to be installed in plasterboard or
false ceiling, as these materials may not support 45kg.
Note: Fastening screws (included) are designed for use
with the fan and are fastened to wooden beams. If the
installation is carried out on a different material, it is advisable to
use the appropriate fixing screws for that material (these screws
are not supplied with this equipment).
