2. Control Board – Warnings and Alarms (Series 5)
HOOD
Hood Warnings
Hood Alarms
79
DISPLAY DESCRIPTION EFFECT POSSIBLE CAUSES SOLUTIONS
WC01
Exhaust probe 1
Warning
One of the two steam
condenser doesn't
work
Probe 1
interrupted or not connected
properly
Check the connection of
exhaust probe 1
Probe 1 damaged Replace hood probe 1
Damaged hood card Replace hood card
WC02
Hood card
temperature Warning
The hood continues to
work
Over heat of the hood card ( <
70°C)
Check possible causes of
that overheat
Hood card damaged Replace hood card
WC03
Exhaust probe 2
Warning
One of the two steam
condenser doesn't
work
Probe 2
interrupted or not connected
properly
Check the connection of
exhaust probe 2
Probe 2 damaged Replace hood probe 2
Damaged hood card Replace hood card
WC10
Wrong settings of non
indispensable
parameters on the
EEPROM
The hood continues to
work (with possible
limits, depends from
the wrong setting of
the parameter in
object)
Damaged hood card Replace hood card
Wrong settings on EEPROM
parameters
Reset hood card parameter
(LMP)
DISPLAY DESCRIPTION EFFECT POSSIBLE CAUSES SOLUTIONS
AC01
Loss of
communication
Hood Stop
Hood card - oven card cable
interrupted or not connected
properly
Check and/or replace the
cable which connect
the power card to the hood
card
Damaged oven power card Replace oven power card
Damaged hood card Replace hood card
High electrical distrurbaces
Reset the main power
supply of the complete
system
AC10
Wrong settings of
indispensable
parameters on the
EEPROM
Hood Stop
Damaged hood card Replace hood card
Wrong parameters
Reset the software with
LPM parameter
