Unox Cheftop Mind.Maps XAVC-06FS-EPR - Technical Data; Oven Model Specifications

16
Oven model**
Trays
type
N° Trays
Dimensions
[inches - mm]
Weight*
[lbs - Kg]
XAVC-0511-EPR
GN 1/1
5
29” 17/32 x 30” 7/16 x 26” 9/16 - 750x773x675 154 lbs - 70 kg
XAVC-0511-MPR 5 29” 17/32 x 30” 7/16 x 26” 5/8 - 750x773x676 154 lbs - 70 kg
XAVC-0711-EPR 7 29” 17/32 x 30” 7/16 x 33” 3/16 - 750x773x843 187 lbs - 85 kg
XAVC-1011-EPR 10 29” 17/32 x 30” 7/16 x 39” 3/4 - 750x773x1010 209 lbs - 95 kg
XAVC-06FS-EPR
18”x26
6
33” 27/32 x 37” 11/16 x 33” 3/16 - 860x957x843 220 lbs - 100 kg
XAVC-06FS-HPR 6 33” 27/32 x 37” 11/16 x 33” 7/32 - 860x957x844 236 lbs - 107 kg
XAVC-10FS-EPR 10 33” 27/32 x 37” 11/16 x 45” 25/32 - 860x957x1163 287 lbs - 130 kg
XAVC-10FS-HPR 10 33” 27/32 x 37” 11/16 x 45” 25/32 - 860x957x1163 302 lbs - 137 kg
XAVC-16FS-EPR 16 34” 23/32 x 41” 1/16 x 73” 15/32 - 882x1043x1866 408 lbs - 185 kg
XAVC-16FS-HPR 16 34” 23/32 x 41” 1/16 x 73” 15/32 - 882x1043x1866 430 lbs - 195 kg
Oven model**
Trays
type
Power S6 [kW]
Power @240V
or @480V
[kW]
Power @208V
or @440V
[kW]
Max heating
power
[kW]
kW/tray kW/m
2
Electrical connection
XAVC-0511-EPR
GN 1/1
7,7 5,8 7,4 1,48 8,59 208-240V/3P/60Hz
XAVC-0511-MPR 5,5 4,1 5,2 1,04 6,04 208-240V/1P/60Hz
XAVC-0711-EPR 13 9,8 12,2 1,74 10,12 208-240V/3P/60Hz
XAVC-1011-EPR 15,5 11,6 14,7 1,47 8,53 208-240V/3P/60Hz
XAVC-06FS-EPR
18”x26
19,1 14,3 18,3 3,05 10,34 208-240V/3P/60Hz
XAVC-06FS-HPR 21,8 18,3 21 3,50 11,87 440-480V/3P/60Hz
XAVC-10FS-EPR 28,7 21,6 27,45 2,75 9,31 208-240V/3P/60Hz
XAVC-10FS-HPR 32,7 27,5 31,5 3,15 10,68 440-480V/3P/60Hz
XAVC-16FS-EPR 47,8 35,9 45,75 2,86 9,69 208-240V/3P/60Hz
XAVC-16FS-HPR 54,5 45,8 52,5 3,28 11,12 440-480V/3P/60Hz
* The values refer to the appliance when empty.
** Oven listed as example have final letter R that means the right to left door opening. All the ovens
with final letter L have the left to right door opening.
TECHNICAL DATA
