UP3D F20 - Hazardous Areas Identification; Operation and Configuration; Operating Instructions

06
Dangerous area Hazard type
Sides of furnace Burn hazard
Lifting areas Crush hazard
Furnace internal parts Electric shock hazard
2.2 Hazardous areas
The hazardous area of the F20 sintering furnace is shown in the table
below:
3.1.1 Operating Instructions
03
Operation and con󽗉guration
Power Switch, switch to I to turn on the
machine and start using.
Switch to O to turn o󽗈 the machine and
stop using.
Power port, connect the con󽗉gured
power cord to this port (the machine
power
Power cable is a speci󽗉c power cable,
and there is a risk of wire burning if
other power cables are used)
Place the sintering tray, put the
restorations in the tray 󽗉lled with
zirconium beads,
and cover the tray cover in sequence
(the tray can be stacked up to
three layers, and a maximum of 40
single crowns can be placed on each
layer)
