07
3.1.2 Control Panel
The main user interface is divided into two parts:
1. Operation area (including lift control button, sintering control
button, electrical parameter display box, sintering program display box,
temperature display box, time display box, fault display box, setting
box, etc.)
2. Sintering curve display area (display sintering curve of current
sintering program and heating rate of each stage, target temperature,
holding time, etc.)
The F20 furnace is equipped with a large colorful touch screen,
all operations can be easily controlled via it.
01
02
3.1.3 Icon Explanation
