UPG 173RM17A - Operational Overview

Operational overview
On-screen display
The buttons (item 1 & 2) are used to operate the UPG 1U Rackmount Console OSD menus.
Callout Component Function
1
OSD activation button
• Launches OSD menu
•
Selects menu options
•
Exits menus and OSD
2
OSD scroll up and down button
Used to scroll in the OSD menu and
adjust the function
