Controls and Indicators
Operation Manual Page 5
C ONTROLS AND I NDICATORS
Figure 2: Controls and Indicators
1 Drive (Hi Speed)
2. Drive (Low Speed)
3. Level
4. Horn Button
5. Lift/Lower Button
6. Glow Plug
7. Engine Start
8. Emergency Stop Button
9. Display
10. Joystick
1. Emergency Stop
2. Elevate
3. Descend
4. Enable
5. Glow Plug
6. Start
Platform Controls
Chassis Controls
10
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
