Service and Repair
3-23
4. Lubricate and piston seal and install the piston and rod assembly into the cylinder barrel.
5. Screw the head cap into the cylinder barrel hand tight and then turn 1/4 turn further.
Installation
Note: Before installing the cylinder, check the pins and bearings for excessive wear. Replace if neces-
sary.
1. Place the cylinder in position taking care to support the cylinder to prevent falling.
2. Install the lower pin and retaining bolt.
3. Install the upper pin and retaining ring.
4. Install both hoses.
5. Raise the machine and check for leaks.
Note: The cylinder may need to be extended and retracted so as to allign the rod end pivot hole.
