6-6
Illustrated Parts Breakdown - Elevating Assembly
SL30SL Service & Parts
Elevating Assembly
SL30SL ~ 505502-000
SL26SL ~ 505602-000
Item Part Description QTY.
1
011254-024 BOLT, PIN LOCK 3/8’ 9
2
064090-000 PIVOT PIN, UPPER T-BAR & UP BOOM - PED 3
3
011248-006 NUT, PIN LOCK 3/8’ 9
4
064111-002 WELDMENT, PEDESTAL (PLATFORM SUP) 1
5
062649-020 BUSHING, ALL 1.75” PINS 12
6
064536-000 UPPER TENSION BAR 1
7
064521-000 UPPER BOOM 1
8
064538-000 CHANNEL, WIRE COVER (UPPER BOOM) 1
9
062642-030 BUSHING, ALL 2.75 PINS 6
10
011248-016 LOCKNUT 1’ 6
11
064089-000 GEAR SEGMENT 2
12
013336-001 GREASE NIPPLE (1/8 BSP) 10
13
064070-002 2nd POST WELDMENT 1
14
064094-000 PIVOT PIN, LOWER T-BAR 2
15
062649-010 BUSHING, LIFT CYLINDER ROD - BOOM 2
16
011253-008 NUT (ROLLER) 1
17
064095-000 PIVOT PIN, LOWER BOOM & UP BOOM - 2nd 3
18
064530-000 LOWER BOOM 1
19
064542-000 CHANNEL, WIRE COVER (LOWER BOOM) 1
20
064093-000 PIVOT PIN, CYL ROD - LOWER BOOM 1
21
064531-001 LOWER TENSION BAR 1
22
114918-048 BOLT (ROLLER, BOOM REST) 1
23
064356-000 ROLLER PIN 1
24
027931-057 BUSHING, ROLLER 2
25
064354-000 ROLLER 1
26
063904-101 CYLINDER, MAIN LIFT 1
27
064320-001 1st POST WELDMENT 1
28
064331-001 LEVELLER WELDMENT 1
29
064092-000 PIVOT PIN, CYL BODY - 1st POST 1
Item Part Description QTY.
1
011254-024 BOLT, PIN LOCK 3/8’ 9
2
064090-000 PIVOT PIN, UPPER T-BAR & UP BOOM - PED 3
3
011248-006 NUT, PIN LOCK 3/8’ 9
4
064111-001 WELDMENT, PEDESTAL (PLATFORM SUP) 1
5
062649-020 BUSHING, ALL 1.75” PINS 12
6
064087-000 UPPER TENSION BAR 1
7
064078-002 UPPER BOOM 1
8
064451-000 CHANNEL, WIRE COVER (UPPER BOOM) 1
9
062642-030 BUSHING, ALL 2.75 PINS 6
10
011248-016 LOCKNUT 1’ 6
11
064089-000 GEAR SEGMENT 2
12
013336-001 GREASE NIPPLE (1/8 BSP) 10
13
064070-002 2nd POST WELDMENT 1
14
064094-000 PIVOT PIN, LOWER T-BAR 2
15
062649-010 BUSHING, LIFT CYLINDER ROD - BOOM 2
16
011253-008 NUT (ROLLER) 1
17
064095-000 PIVOT PIN, LOWER BOOM & UP BOOM - 2nd 3
18
064060-003 LOWER BOOM 1
19
064450-000 CHANNEL, WIRE COVER (LOWER BOOM) 1
20
064093-000 PIVOT PIN, CYL ROD - LOWER BOOM 1
21
064084-001 LOWER TENSION BAR 1
22
114918-048 BOLT (ROLLER, BOOM REST) 1
23
064356-000 ROLLER PIN 1
24
027931-057 BUSHING, ROLLER 2
25
064354-000 ROLLER 1
26
063904-101 CYLINDER, MAIN LIFT 1
27
064320-001 1st POST WELDMENT 1
28
064331-001 LEVELLER WELDMENT 1
29
064092-000 PIVOT PIN, CYL BODY - 1st POST 1
