6-22
Illustrated Parts Breakdown - Hydraulic Cylinders : Steer, Axle Float, Tilt
SL30SL Service & Parts
Hydraulic Cylinders : Steer, Axle Float, Tilt
Steer Cylinder
063905-101
Item Part Description QTY.
1 063905-010 SEAL KIT 1
Tilt Cylinder
064345-100
Item Part Description QTY.
1 064345-010 SEAL KIT 1
Axle Float Cylinder
064642-100
Item Part Description QTY.
1 066642-010 SEAL KIT 1
