- 7 -
2
Product Setup
- 8 -
Attach the “Sensor Cover” using the
cover strap (attachment wire) and the
strap holes.
1
Replace the back cover.
5
Install the battery as shown with the
correct orientation. The battery will install
in only one direction – do not force the
battery in.
4
Use the Power Adapter cable supplied in
the packaging to connect it to the
MK350S and charge the battery – the
battery recharge light will flash if
recharging and will stop flashing when
fully charged.
(Charge for 6 hours on this first time use)
6
You can attach a lanyard (neck strap)
onto one of the two strap holes on top of
the corners of the MK350S unit.
2
Remove the back cover from underneath
the MK350S by inserting your fingernail
into the notch, located below the end of
the cover, and sliding your nail along the
underside of the edge to unhinge one
side - do the same for the other side.
3
notch
To Next Page
