8
DS1160-008
1.1. INDICATOR LEDS
The functions of the components listed in the paragraph above are shown in detail below.
6. Multicolour indicator LED
FUNCTIONS
Slowly blinking yellow: programming state on
Fast green blinking: confi rm pressing of the button
s or
Slow red blinking: ringer mute
Slow green blinking: automatic door opener active
9. Green LED under the button
On steady: call in progress
On blinking: conversation ongoing
11. Green LED under the button
on blinking (max. 3 seconds): door opener confi rmation after pressing button
1.2. BUTTON FUNCTIONS
State
Button
STAND-BY
WAITING
FOR
PICK-UP
(RECEIVING
CALL)
DURING
AUDIO
OPERATION
IN STAND-BY
AND ONLY
AFTER PRESSING
BUTTON
STATE OF
PROGRAMMING
(1)
(ONLY WITH DOOR PHONE
IN STAND-BY)
Open
pedestrian
door
(3)
Open
pedestrian
door
Open
pedestrian
door
Open pedestrian
door
Connect / disconnect the automatic door
opening system
---
Audio
activation
End of current
conversation
---
Call volume adjustment for door and fl oor
level calls (the possible volume adjustments
are, in this order, LOW, HIGH, MUTE)
Special
function
(2)
Special
function
(2)
Special
function
(2)
Call to switchboard
or intercom
(2)
Call source selection (from main calling
station, from secondary calling station, to
fl oor, intercom, from switchboard)
Garage
door opener
or special
function
(2)
Garage
door opener
or special
function
(2)
Garage
door opener
or special
function
(2)
Call to switchboard
or intercom
(2)
Call tone selection
(1)
To enter and exit programming state, hold button pressed for longer than 5 seconds. Three fast
beeps will be heard and the yellow LED will blink slowly to indicate that programming mode is selected.
Programming mode will shut down in all cases after the 10 minute timeout (two long beeps will be
heard).
(2)
If confi gured beforehand.
(3)
According to how the door opener is programmed: free or secret.
