Convert Server User Manual www.usr iot
.
c o
m
Jinan USR IOT Technology Limited 16
/
41 tec@usr.cn
TCP/UDP Linking Parameters
Protocol Type
Link Type （ Server or Client ）
Target Port ID Number
Target Port IP Address
Serial Port Parameters
Baud Rate
Data Bit
Parity (Check) Bit
Stop Bit
Hardware Flow Control
Work Mode Selection
Transparent transmission /Serial command mode/GPIO mode/HTTPD Client mode
The following sections will introduce specific to each part in detail.
5.2.
5.2.
5.2.
5.2. Working
Working
Working
Working mode
mode
mode
mode
5.2.1.
5.2.1.
5.2.1.
5.2.1. Transparent
Transparent
Transparent
Transparent Transmission
Transmission
Transmission
Transmission Mode
Mode
Mode
Mode
Convert Server support serial interface transparent transmission mode. The benefit of this mode is achieves
a plug and play serial data port, and reduces user complexity furthest. In this mode, user should only
configure the necessary parameters. After power on, Convert Server can automatically connect to the default
wireless network and server.
As in this mode, the Convert Server 's serial port always work in the transparent transmission mode, so users
only need to think of it as a virtual serial cable, and send and receive data as using a simple serial. In other
words, the serial cable of users
’
original serial devices is directly replaced with the Convert Server ; user
devices can be easy for wireless data transmission without any changes.
The transparent transmission mode can fully compatible with user ’ s original software platform and reduce the
software development effort for integrate wireless data transmission.
Notes:
Notes:
Notes:
Notes: Users also open the serial port hardware flow control (CTS/RTS) function, so that we can make the bit
error rate to a minimum.If the user doesn't need hardware flow control function of the serial port, only need to
the corresponding pin foot (CTS/RTS) hung up.
