USR IOT RS232 User Manual

Convert Server User Manual www.usr iot . c o m
Jinan USR IOT Technology Limited 4 / 41 tec@usr.cn
1.
1.
1.
1. Quick
Quick
Quick
Quick Start
Start
Start
Start
This chapter is the quick start for Convert Server . proposal user read this chapter and follow the instructions.
This will help your understanding of the product. Of course, the user can choose read chapters according to
need . For specific details and instructions, please refer to the following.
1.1.
1.1.
1.1.
1.1. Hardware
Hardware
Hardware
Hardware connect
connect
connect
connect
In order to test the serial port to the WIFI/ Ethernet communication transformation,connect the the device
serial port to PC serial port, connect the device WIFI/Ethernet to PC WIFI/Ethernet .If the desktop does not
own the serial port, also can use USB 232 to replace. The hardware environment.
Ethernet
DC 5 - 18 V
232
485
S elect Ethernet
or WIFI
Select 232 or
485
Figure
Figure
Figure
Figure 1
1
1
1 Hardware
Hardware
Hardware
Hardware Connect(610)
Connect(610)
Connect(610)
Connect(610)
According to the above connect Convert Server.
1.2.
1.2.
1.2.
1.2. Network
Network
Network
Network connection
connection
connection
connection
Open Wi-Fi, search network on the PC , as shown in below, USR-WIFI232- AP_3378 is the default network
name (SSID) of the Convert Server .
Note: if the firmware version is V4, the SSID is "HF - A11x_AP".After the SSID is also like this.
