USR IOT RS232 User Manual

Convert Server User Manual www.usr iot . c o m
Jinan USR IOT Technology Limited 31 / 41 tec@usr.cn
with the target IP address and communication.When set to the TCP Server, do not need to enter the IP
address.For other Settings, need to fill in the need to connect each other IP address.Fill in port with protocol
port number, at the ends of the communication port number must be the same.
The Socket B only as a TCP client terminal to communicate with the server.
TCP connection password authentication: when the Convert Server in the TCP server mode, password
authentication on the TCP client connect to.
Note: this verification is only in a Convert Server as a TCP server.After the opening, the TCP client connected
Convert Server , the first data which sent to the Convert Server is password and carriage returns.The
password is the password to login page default is "admin".Such as the default when sending the first data
should be "0x61 0x64 0x6D 0x69 0x6E 0x0D 0x0A" (hex) .
6.1.7.
6.1.7.
6.1.7.
6.1.7. Ethernet
Ethernet
Ethernet
Ethernet Setting
Setting
Setting
Setting
This page is used to set two Ethernet front-end ports of the Convert Server , two Ethernet front-end ports
can be open or closed.And so the second can be set to the WAN port to use, this Convert Server can be used
as a secondary router, making it easy for users to network.Specific Settings page is as follows:
Figure
Figure
Figure
Figure 16
16
16
16 Ethernet
Ethernet
Ethernet
Ethernet Setting
Setting
Setting
Setting Page
Page
Page
Page
6.1.8.
6.1.8.
6.1.8.
6.1.8. HTTPD
HTTPD
HTTPD
HTTPD Client
Client
Client
Client Mode
Mode
Mode
Mode
This page sets the HTTP header in the HTTPD Client mode.Include: the address of the server, the server port,
request type, protocol header path, Connection, user-agent.
HTTPD Client mode support POST, PUT, GET three HTTP request types.Is a POST or PUT request way,
serial data can be added to the back of the HTTP header;When the request is a GET, data can be added to
the back of the path in the HTTP header.The specific way of sending data can consult section 4.2.4.
