 PC Setting:
 IP address: 10.10.100.100;
 Network Protocal:TCP/Server, Port ID: 8899;
 Convert Server 1# Setting:
 Works as AP mode;
 LAN IP address: 10.10.100.254;
 Network Protocal:TCP/Client, Port ID: 8899; Application IP address:10.10.100.100;
 Convert Server 2# Setting:
 Works as STA mode;
 WAN connection type: Static IP: 10.10.100.101;
 Network Protocal:TCP/Client, Port ID: 8899; Application IP address:10.10.100.100;
 LAN IP address: 10.10.99.254 (Different net segment with WAN port);
 Convert Server 3# Setting:
 Works as STA mode;
 WAN connection type: Static IP: 10.10.100.102;
 Network Protocal:TCP/Client, Port ID: 8899; Application IP address:10.10.100.100;
 LAN IP address: 10.10.98.254 (Different net segment with WAN port);
