USSC APS1100B - Repair Parts

13
REPAIR PARTS
1 Hex Head Bolt 83432 3
2 3/8 ID Washer 83045A 3
3 Flue Collar 40292 1
4 Flue Collar Gasket 88042 13
5 Weld Tab 83431 1
6 Firebox Weldment Af0040A 1
7 Top Plate Trim AF0027 1
8 Brass Handle Af0019 1
9 Hearth Trim AF0028 1
10 Keps Nus 83274 1
11 Door Latch Spacer AF0034 1
12 Door Latch AF0007 1
13 Door Latch Bushing AF0035 1
14 10-24 x 3/8 PH Bolt 83202 4
15 Bottom Bracket AF0024 1
16 Door Glass AF0038 1
17 Glass Gasket 88087 1
18 Door Gasket 88066 1
19 Feed Door AF0036 1
20 Door Handle AF0020 1
21 Brass Handle 89574 1
22 Top Bracket AF0025 1
23 Door Hinge Pin AF0023 2
24 Firebrick (4.5 x 9 x 1.25) 89066 12
25 Firebrick (4.5 x 7.38 x 1.25) AF0021 4
26 Firebrick (5.19 x 9.25 x 1.25) AF0055 2
KEY NO. DESCRIPTION PART NO. QTY.
