13.1 CRANKCASE ASSY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
NO. PARTS NO. DESCRIPTION
QTY
QJ182QDP.01-11
157.5-10
157.5-9
QJ150FMG.5-8
GB5787-86
QJ182QDP.01.04
157-1-6-13
QJ182QDP.01-01
QJ168QDJ.01-05
QJ168QDJ.01-03
GB5787-86
QJ182QDP.01.01
QJ168QDJ.01-04
QJ182QDP.01-03
GB/T276-94
GB/T276-94
QJ182QDP.01-10
QJ182QDP.01-05
QJ182QDP.01-09
QJ182QDP.01-08
GB5787-86
QJ182QDP.01.03
QJ182QDP.01.02
Buse, locating
SPACER, drain
BOLT, drain
DOWEL PIN
BOLT M6 12
Sensor Assy, Fuel level
NUT
COVER, CRANKCASE
SEAL WASHER
PLUG, ADD OIL
BOLT M8 40
OIL SEAL 52 34 8
OIL LEVEL STICK
SPACER, CRANKCASE
Bearing6202 15 35 11
Bearing6207 35 72 17
Pin
ELECTRONIC SWITCH
CLIP, Cord
SEAL GASKET, rubber
BOLT M6 25
OIL SEAL
CRANKCASE ASSY
2
2
2
2
4
1
1
1
2
1
7
2
1
1
2
1
1
1
1
1
2
1
1
12.WHEEL KIT
13.PARTS LIST AND DIAGRAM
- 13 -
1.Install the two wheels on the
generator using two bolts .
2.Install the crutches on the under frame.
2.Install the handrails on the right frame.
CRUTCHES
WHEELS
HANDRAILS
BOLTS
