Utax P-4030D User Manual

4-109
Operation Panel
4 When the initialization is finished Task is completed. is
displayed. Turn the power switch off and then on.
DataSanitization (Sanitizing the stored data)
This is to completely delete the address information registered on the machine and the stored image data.
1 In the Data Security menu, press  or  to select
DataSanitization.
2 Press [OK]. A confirmation message is displayed.
3 Press [Yes] ([Left Select]). The message Sanitizing the
data. appears and the data sanitization begins.
Pressing [No] ([Right Select]) returns to the Data Security
menu without sanitizing the data.
4 When the data sanitization is finished Complet is displayed. Press
[OK] ([Right Select]) and turn the power switch off.
Task is completed.
Turn the main power
switch off and on.
IMPORTANT To complete this process requires about 30 minutes when an optional SSD (HD-6) is installed and a few
minutes when an SSD (HD-6) is not installed.
You can only performing this operation by logging in with machine administrator privileges.
It is not possible to cancel the process once it has started.
Remove the USB cable and network cable, etc., before performing this operation.
Do not turn off the power supply whilst the deletion is ongoing. If the power switch off during the deletion then the deletion
will automatically be performed when the power is switched back on, but a complete operation cannot be guaranteed.
The data deleted is as listed below.
• Job settings
• Machine settings (Network settings)
• Certificates
• User settings (user list, document boxes)
• Machine administration (job logs, job accounting)
Note It is possible to check the status of data sanitization implementation on the Status page. For details, refer to
Status Page (Printing a printer's status page) on page 4-12.
Note When an optional SSD (HD-6) is installed, the printer
automatically restarts before data sanitization.
Note It is possible to check the result of data sanitization on
the Status page. For details, refer to Status Page (Printing a
printer's status page) on page 4-12.
Sanitize the data.
Are you sure?
* This process will
take a while.
[ Yes ] [ No ]
Sanitizing the data.
Main Memory :Complet
Internal Mem.:Complet
[ OK ]

Utax P-4030D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	21 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.5
Total input capacity	500 sheets
Total output capacity	250 sheets
Paper tray media types	Glossy paper, Matte paper, Plain paper
Paper tray media weight	60 - 120 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	USB 2.0
Optional connectivity	Wireless LAN
Internal memory	128 MB
Compatible memory cards	SD
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	11.5 W
Power consumption (printing)	564 W
Power consumption (PowerSave)	3 W
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	410 mm
Width	390 mm
Height	285 mm
Weight	13500 g
