Utax P-5030DN Service Manual

2LV/2L1/2L2/2MS/2MT
2-3-3
YC2 A13 C2P_LCDCO
N
O 0/3.3 V DC Panel LCD control signal
Connected to
the engine
PWB
B13 P2C_PKEY I 0/3.3 V DC Panel start signal
A14 C2P_BUZCO
N
O 0/3.3 V DC Panel buzzer control signal
B14 FUPRST O 0/3.3 V DC Panel reset signal
A15 GND - - Ground
B15 GND - - Ground
A16 VBUS O 5V DC 5 V DC power output to USB
B16 UDATAP I/O - USB data signal
A17 GND - - Ground
B17 UDATAN I/O - USB data signal
A18 GND - - Ground
B18 GND - - Ground
A19 +5V2 I 5 V DC 5 V DC power input from EPWB
B19 +5V2 I 5 V DC 5 V DC power input from EPWB
A20 +5V2 I 5 V DC 5 V DC power input from EPWB
B20 +5V2 I 5 V DC 5 V DC power input from EPWB
YC5 1 VDD5 O 5 V DC 5 V DC power output to eKUIO
Connected to
the eKUIO IF
2 GND - - Ground
3 RESETN O 0/3.3 V DC Reset signal
4 VDD5_CUT O 0/3.3 V DC Sleep signal
5 GND - - Ground
6 WAKEUP I 0/3.3 V DC Wake-up signal
7 AUDIO I 0/3.3 V DC Audio signal
8 NC - - Not used
9 NC - - Not used
10 NC - - Not used
11 GND - - Ground
12 NC - - Not used
13 NC - - Not used
14 GND - - Ground
15 NC - - Not used
16 NC - - Not used
17 GND - - Ground
18 USB_DP I/O - USB data signal
19 USB_DN I/O - USB data signal
20 VBUS O 5 V DC 5 V DC power output to eKUIO
Connector Pin Signal I/O Voltage Description

Utax P-5030DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Duplex print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.5, PostScript 3
Total input capacity	500 sheets
Paper tray media types	Glossy paper, Matte paper, Plain paper
Paper tray media weight	60 - 120 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Internal memory	256 MB
Processor model	465
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	12.8 W
Power consumption (printing)	677 W
Power consumption (PowerSave)	1.6 W
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	410 mm
Width	390 mm
Height	320 mm
Weight	14600 g
