Utax P-5030DN Service Manual

2LV/2L1/2L2/2MS/2MT-4
2-4-4
Printing concentration D4 1: Thin.
2: Slightly Thin.
3: Standard
4: Slightly Deep.
5: Deep.
3
Total host buffer size H8 0 to 99 in units of the size defined by FRPO S5 5
Form feed time-out value H9 Value in units of 5 seconds (0 to 99). 6
KIR mode N0 0: Off
2: On
2
Duplex binding N4 0: Off
1: Long edge
2: Short edge
0
Sleep timer time-out time N5 1 to 240 minutes [0: Off] (U.S.A and other)
1 to 120 minutes [0: Off] (Euro only)
1
1
11(40ppm
with network)
Ecoprint level N6 0: Off
2: On
0
Resolution N8 0: 300dpi
1: 600dpi
3: 1200dpi
1
Parallel interface mode O0 0: Standard Mode
1: Fast Mode
5: Nibble (High Speed) Mode
70: Automatic Mode
70
Parallel interface Error control O2 0: Line Control OFF
2: Compatibility with PCL
2
Default emulation mode P1 0 : Line printer
1 : IBM proprinter
2 : DIABLO 630
5 : Epson LQ-850
6 : PCL6 (except PCL XL)
8 : KC-GL
9 : KPDL
11 : PC-PR201
12 : IBM 5577
13 : VP-1000
14 : N5200
15 : FMPR-359F1
9(U.S.A)
or
6(Euro and
other)
Carriage-return action * P2 0: Ignores 0x0d
1: Carriage-return
2: Carriage-return+linefeed
1
Linefeed action * P3 0: Ignores 0x0d
1: Linefeed
2: Linefeed+carriage-return
1
Item FRPO Setting values
Factory
setting

Utax P-5030DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Duplex print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.5, PostScript 3
Total input capacity	500 sheets
Paper tray media types	Glossy paper, Matte paper, Plain paper
Paper tray media weight	60 - 120 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Internal memory	256 MB
Processor model	465
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	12.8 W
Power consumption (printing)	677 W
Power consumption (PowerSave)	1.6 W
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	410 mm
Width	390 mm
Height	320 mm
Weight	14600 g
