UTC Fire and Security DET-TRONICS 95-8533 User Manual

7.1 95-85336-8
EQ3740IPM INTELLIGENT
PROTECTION MODULE
POWER REQUIREMENTS—
3 watts nominal, 7 watts maximum.
INPUT VOLTAGE—
24 vdc nominal, 18 to 30 vdc. 10% overvoltage will
not cause damage to the equipment.
LON COMMUNICATIONS—
Digital communication, transformer isolated (78.5
kbps).
TEMPERATURE RANGE—
Operating: –40°F to +185°F (–40°C to +85°C).
Storage: –67°F to +185°F (–55°C to +85°C).
HUMIDITY RANGE—
0 to 95% RH, non-condensing.
DIMENSIONS—
Refer to Figure 6-3.
SHIPPING WEIGHT—
1 pound (0.45 kilograms).
CERTIFICATION—
FM / CSA: Class I, Div. 2, Groups A, B, C, D (T4).
Class I, Zone 2, Group IIC (T4).
Special conditions for safe use:
Electronic assembly must be installed in a suitable
NRTL labled NEMA rated enclosure.
CENELEC/CE: ATEX/EMC Directive Compliant.
0539
FM
®
II 3 G
EEx nC IIC T4
DEMKO 03 ATEX 136206U
T4 (Tamb = –40°C to +85°C).
Special conditions for safe use:
The device shall be installed in an enclosure that
complies with all relevant requirements of EN 50021:
1999, and provides a degree of ingress protection of
at least IP54. The device may only be installed,
connected or removed when the area is known to be
non-hazardous.
INPUT / INITIATING DEVICE CIRCUITS - CONTACT
MONITOR TYPE - CHANNEL 1 - 3
NOTE
An input must be active for at least 750
milliseconds in order to be recognized.
UNSUPERVISED INPUT—
Two state input (on/off).
Normally open contact.
No EOL resistor required.
SUPERVISED INPUT, CLASS B STYLE B—
Two state input (active/trouble):
End of Line Resistor 10 K ohms ±20%
Open Circuit > 45 K ohms
Active Circuit < 5 K ohms.
SUPERVISED INPUT, CLASS B STYLE C—
Three State input (active/short/open):
End of Line Resistor 10 K ohms ±20%
In Line Resistor 3.3 K ohms ±20%
Open Circuit > 45 K ohms
Short Circuit < 1.4 K ohms
Active Circuit 2.5 K ohms to 5 K ohms.
INPUT CIRCUITS - TWO WIRE SMOKE/HEAT TYPE -
CHANNEL 4 AND 5
SUPERVISED INPUT, CLASS B STYLE B or
CLASS B STYLE C:
Up to 15 two wire detectors per circuit.
Maximum line resistance 50 ohms
Style B, 5K ohm EOL
Open circuit fault impedance 22K ohms
OUTPUT / NOTIFICATION / RELEASING OR
UNSUPERVISED DEVICE CIRCUITS - CHANNEL 6-8
UNSUPERVISED OUTPUT RATING—
Rating: 2 amperes at 30 Vdc maximum.
Note: Voltage available at outputs is dependent on
input voltage (Vout ≈ Vin – 1 Vdc).
OUTPUT STYLE—
Form "A" normally off.
RESPONSE TIME—
Output actuates in <0.15 second after acknowledging
an alarm command message.
No EOL resistor required.
