1717
Tilt Lever [13]Tilt Lever [13]
Move lever backward to tilt mast backward. MoveMove lever backward to tilt mast backward. Move
lever forward to tilt mast forward.lever forward to tilt mast forward.
Control tilt speed with tilt lever and acceleratorControl tilt speed with tilt lever and accelerator
pedal.pedal.
CAUTIONCAUTION
The tilt lock mechanism in the hydraulicThe tilt lock mechanism in the hydraulic
control valve will not allow the mast to tiltcontrol valve will not allow the mast to tilt
forward while the engine is being shut down,forward while the engine is being shut down,
even if the tilt lever is pushed forward.even if the tilt lever is pushed forward.
Side Shift Control Lever [14]Side Shift Control Lever [14]
Used for left shifting and right shifting of the sideUsed for left shifting and right shifting of the side
shift bracket.shift bracket.
Push forwardPush forward--move to the leftmove to the left
Pull backwardPull backward--move to the rightmove to the right
Side shifting speed depends on the tilting angel of theSide shifting speed depends on the tilting angel of the
handle and accelerator control.handle and accelerator control.
