Utilitech SFSDE-500B-A - Assembly Instructions; Step-by-Step Assembly Guide

AA
AA
HARDWARE USED
Screw
x4
AA
HARDWARE USED
Screw
x2
2. Insert the U-bracket on the fan body (A) into the standing pole (B), then secure with screws (AA)."
4
AA
ASSEMBLY INSTRUCTIONS
1. Insert 4 screws (AA) through the holes in the stand pole (B), then attach the stand
pole to the base (C).
B
B
C
A
B
