ASSEMBLY INSTRUCTIONS
Post Installation Level
20. If needed, at panel can be leveled +/– 3 degrees.
Note: Leveling will be difcult if mounting arm
screws (PP) are too tight.
Adjust Tilt
21. To adjust tilt, loosen tilt lever and move panel to
desired position. Tighten tilt lever to hold desired tilt.
