V2 CALYPSO Series User Manual

- 63 -
g max
B [mm] C [mm]
F
[mm]
90°
130 170 1200
150 180 1190
170 180 1190
190 190 1180
210 190 1170
230 190 1170
250 180 1170
270 190 1170
290 170 1180
g max
B [mm] C [mm] F [mm]
90°
295 280 1290
315 295 1300
335 265 1310
g max
B [mm] C [mm] F [mm]
100°
175 190 1390
195 200 1370
215 220 1360
235 235 1350
255 255 1330
275 270 1300
g max
B [mm] C [mm] F [mm]
110°
195 200 1370
215 220 1360
235 235 1350
255 250 1335
g max
B [mm] C [mm]
F
[mm]
100°
130 160 1210
150 170 1200
170 170 1200
200 180 1190
210 170 1190
230 190 1170
250 180 1180
270 160 1200
280 160 1200
g max
B [mm] C [mm]
F
[mm]
110°
130 170 1200
150 180 1190
170 180 1190
190 190 1180
210 200 1170
220 200 1170
CALYPSO 500
CALYPSO 600

V2 CALYPSO Series Specifications

General

Power Supply	24V DC
Connectivity	Ethernet, USB
Display	Touchscreen LCD
Communication Ports	Ethernet, USB
Buttons	User-definable buttons
