Page #2 background imageLoading...
Page #2 background image
177 mm120 mm
A
B
C
ø12,5 mm
ø13 mm
120 mm59,5 mm
6 mm
6 mm
10 mm
8,5 mm
80 mm
50 mm
CALYPSO 400 500 600
A 819 944 1044
B 762 887 987
C 1162 1387 1644

Table of Contents

Other manuals for V2 CALYPSO Series

Preview: Instructions
Instructions68 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the V2 CALYPSO Series and is the answer not in the manual?

V2 CALYPSO Series Specifications

General IconGeneral
Power Supply24V DC
ConnectivityEthernet, USB
DisplayTouchscreen LCD
Communication PortsEthernet, USB
ButtonsUser-definable buttons
