V2 Easy3 User Manual

ENGLISH
27
FUNCTION TABLE (the highlighted boxes indicate the factory default settings)
FUNCTION
(LED)
LED OFF LED ON
6. dm/fire
MAN PRESENT LOGIC INACTIVE
By simply using the start command, the
user can activate the automation device
in opening or closing.
The maximum duration of opening or
closing depends on the operating time
set
MAN PRESENT LOGIC ACTIVE
The user must press and hold the start button
for the entire duration of the desired opening or
closing procedure.
The maximum duration of opening or closing
depends on the operating time set.
MAN PRESENT logic may be implemented with
both Start/Stop and Up/Down logic.
The STOP command interrupts the operational
cycle, independently of the status of the control
inputs. Hence, if the UP or DOWN button is
pressed, the action of STOP is to stop motion,
and on its release the motor DOES NOT MOVE
UNTIL THE UP or DOWN INPUT IS RELEASED
AND PRESSED ONCE MORE
PLEASE NOTE: when the Man-Present
function is enabled, radio-controlled
operation is disabled
7. light/canc
FLASHING
Output (E1 - E2) is on intermittently (2
Hz) during opening and closing and
during pause mode, if automatic
reclosing is active
COURTESY LIGHT
The output (E1 - E2) is on and fixed during
opening, pause and closure. Having completed
the operating cycle, the light remains on for the
COURTESY LIGHT OFF DELAY time
8. motor/test
/error
PHOTOCELL TEST INACTIVE
The photocell operation test is not
performed
PHOTOCELL TEST ACTIVE
Each time the control unit receives an open or
close command, the PHOTOCELL TEST verifies
that the PHOTOCELL is operating correctly.
If the test fails, the photo LED flashes at 2 Hz
for 5 seconds, together with the
motor/test/error LED
