VABCHES D8L239BS02 - D8 L239 BS02-梳妆台-说明书-2022-12-16-31; 图纸和视图; 模型

STEP22
32-42
X50
8
X1 set
Ø3X14mm
17
90°
90°
90°
90°
Before attaching the back panel,
be sure that the unit is at 90°.
Align the semicircular holes
to form a circular hole
17
8
A
J
JJ
J
J
V
Pass the power plug through
this hole.
