STEP25
35-42
A
C
B
To adjust depth.
Loosen screw "B" and adjust door, if the door can
not be adjusted, please loosen screw "C", then try
again. Tighten screw "B" and "C".
To adjust side ways.
Turning the screw "C" on BOTH hinges on each
door.
To adjust the vertical height.
Loosen the four screws "A" on both hinges.
Two of them are usually in slotted holes which
allows you to adjust up or down by a few mm.
Then tighten back up.
Door
Cabinet
Door
Cabinet
Door
Cabinet
