VABCHES D8L239BS02 - D8 L239 BS02-梳妆台-说明书-2022-12-16-08; 图纸和视图; 模型

Part List
Ø15X9.5mm
1
CAM LOCK
spare:3
X45
9-42
Ø6.5X35mm
2
CAM BOLT
spare:3
X45
Ø8X30mm
3
WOODEN DOWEL
spare:3
X32
Ø6X30mm
4
WOODEN DOWEL
spare:3
X50
Ø6.3X50mm
5
SCREW
spare:2
X18
Ø4X40mm
6
SCREW
spare:3
X42
Ø3.5X14mm
7
SCREW
spare:3
X60
Ø3X14mm
8
SCREW
spare:3
X50
M4X18mm
9
SCREW
spare:1
X10
107X10X21mm
X5
Ø5X17mm
X8
HINGE
X6
HANDLE
SHELF SUPPORT
spare:1
14
PERFECT STICKER
spare:3
X44
15CL
LEFT CABINET MEMBER
X3
HEXAGON WRENCH
X1
Ø25mm
4X65mm
15CR
RIGHT CABINET MEMBER
X3
350mm
10 11 12
13
14"14"
350mm
Ø21mm
