X1 set
40-42
1.make mark on
the wall
WALL
2.drill two Ø6
holes on the
wall
WALL
3.put two
anchors in the
holes
1 2 3
5.Push the cabinet close to the wall so
that the two bases are close to each
other, and then put on nylon tie to
tighten it.
Install the tipping
restraint hard ware
4.fix the device on the
wall by the long srews
4
We have included a set of tipping restraint hardware for
this unit. You must install this hardware to prevent
accidents or injuries that can result from the unit falling.
When properly installed, this restraint can provide
protection against the unexpected tipping of the unit due to
small tremors, bumps or climbing. We strongly recommend
mounting this hardware to a wall stud and your unit.
NOTE:The tipping restraint hardware included is for
wooden stud wall construction. It must be attached to a
wall stud. Depending upon your wall construction different
anchor hardware maybe required. Please contact your local
hardware store for assistance. Young children can be
seriously injured by tipping furniture. You must install the
tipping restraint hardware with the unit to prevent the unit
from tipping, causing any accidents or damage. The tipping
restraints are intended only as a deterrent and are not a
substitute for proper adult supervision. The tipping
restraints are not earthquake restraints. If you wish to add
the extra security of earthquake restraints, they must be
purchased and installed separately.
WALL
17
5
STEP30
