ASSEMBLY
1. Align the primary hose storage clip with the bracket as shown (Fig. 1). Slide the hose storage
clip downwards until it is secured into place.
2. Align the secondary hose storage clip with the bracket as shown (Fig.2). Slide the hose storage
clip downwards until it is secured into place.
3. Attach the tough stain tool onto the end of the suction hose until it clicks into place (Fig. 3).
To remove: Press the tool release button and pull away.
NOTE: Wrap the suction hose into the hose storage clips when not in use (Fig. 4).
4. Wrap the power cord loosely around the quick release cord hooks (Fig. 5).
NOTE: Make sure to wrap the power cord around the lower cord hook rst to avoid damaging the
power cord.
