OPERATION
1. Switching On/Off
Connect the mains plug to a suitable power outlet.
Position Status
I on
O off
II automatic synchronized start-up
ASSEMBLY
NOTE: A Phillips screwdriver is required.
1. Remove all the contents from inside of the vacuum cleaner container.
2. Attach the carry handle into the slots located on the top of the power head (Fig. 1).
3. Turn the container upside down and insert the feet with casters into the slots and apply
pressure until they click into place. Secure them with supplied screws (Fig. 2).
4. To position the hose storage rack, insert one end into the channel on the side of the power
head, making sure it is secured in place. Apply inward pressure to the other side and insert it
into the opposite channel (Fig. 3).
5. Your vacuum cleaner comes ready for dry vacuum cleaning with the cartridge lter pre-installed.
If the cartridge lter is not installed, refer to page 12.
6. Optionally, for improved dust ltration, fully t the dust bag ange onto the inlet stub (Fig. 4).
7. For wet vacuum cleaning, replace the cartridge lter with the foam lter supplied. Do not use a
dust bag when wet vacuuming. If the foam lter is not installed, refer to page 13.
8. Secure the power head back on the container using the latches. Insert the locking end of the
hose into the suction port of the container. Ensure the push clip is securely positioned (Fig. 5).
9. Choose the desired accessories and/or extension wands and push t onto the hose nozzle.
Floor Nozzle Attachments
The oor nozzle comes supplied with additional attachments to ensure correct suction across
different oor surfaces and applications.
1) To remove the oor nozzle attachments, turn the oor tool holder upside down.
2) Using a athead screwdriver or other suitable tool, locate the holding clips on each outer edge.
Insert a at edged object directly next to the holding clip, between the insert and the oor tool
holder. Pry the attachment up from underneath (Fig. 6 & 7).
3) Insert the new attachments into the holder applying downwards pressure (Fig. 7).
4) The attachments can be used in three combinations (Fig. 8):
Brush and Squeegee Combination: For use with mixture of wet or dry liquids.
Dual Brush Combination: For use with dry materials or carpeted oor surfaces.
Dual Squeegee Combination: For use on hard oor with wet liquids
Note: The textured side of the rubber squeegee must be facing outwards.
