UNPACKING & CHECKING CARTON
CONTENTS
A
C
D
I J
E
B
G
HF
L
M
N
K
O
P
Remove all contents from the box. Remove
the power head and take out any contents
inside the collection tank. Check each item
against the carton contents list.
Carton Contents List:
Key Description.......…....……….….... Qty.
1
1
1
2
1
1
1
1
1
1
1
4
1
2
1
1
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Vacuum Assembly.…....….….........
Handle......................…....………...
Hose...................…....….…...........
Extension Wands...........................
Floor Brush/Squeegee Nozzle........
Utility Nozzle..................................
Crevice Tool...................................
Dust Bag........................................
Cartridge Filter...............................
Filter Retainer................................
Foam Wet Filter..............................
Caster Foot Assembly....................
6 Screws (Bag)..............................
Hose Storage Racks......................
Drain Cap......................................
Operator’s Manual.........................
NOTE: The hose and accessories for this
vacuum are 1-7/8'' (3.8 cm) diameter.
Power Cord
Storage
Collection Tank
Hose Storage Rack
Handle
Filter Cleaning Button
Blower Port
Vacuum Port
Drain Port
Caster
Accessory Storage
Caster Foot
Latch
On/Off Switch
Power Head
