VADDIO USB 3 - Specifications

12
Specifications
RANGE
Point-to-Point Up to 100m (328 ft) over CAT6a/7 Cable
USB DEVICE SUPPORT
Maximum Throughput 5 Gbps
Traffic Types All Traffic Types
Device Types All Device Types
Maximum Number of Devices and/or Hubs Up to 30 devices
LOCAL EXTENDER
USB Connector 1 x USB 3.1 Gen 1 Type B Receptacle
Link Connector 1 x RJ45 “LINK”
Network Pass Through: 1 x RJ45 “LAN”
Dimensions 137.3mm x 232.1mm x 33.0mm (5.4” x 9.1” x 1.3”)
Enclosure Material Black Anodized Aluminum
Power Supply 100-240V AC Input, 24V 1A DC Output
REMOTE EXTENDER
USB Connector 4 x USB 3.1 Gen 1 Type A Receptacles
Link Connector 1 x RJ45 “LINK”
Network Pass Through: 1 x RJ45 “LAN”
Dimensions 137.3mm x 232.1mm x 33.0mm (5.4” x 9.1” x 1.3”)
Enclosure Material Black Anodized Aluminum
Available Current Up to 1.2 Amp (6W) to each USB port
Power Supply 100-240V AC Input, 24V 2.71A DC Output
ENVIRONMENTAL
Operating Temperature Range 0°C – 50°C (32°F – 122°F)
Storage Temperature Range -20°C – 70°C (-4°F – 158°F)
Operating Humidity 20% to 80% relative humidity, non-condensing
Storage Humidity 10% to 90% relative humidity, non-condensing
COMPLIANCE
EMC FCC (Class B), CE (Class B)
Environmental RoHS2 (CE)
