Main component 08a Hydraulic parts
TURBOmax Pro/Plus VUW 242 -3, 282 -3, 242 -5, 282 -5 H/B (inc. ../2)
Pro 24 E H Pro 28 E H Plus 824 E H Plus 824 E B Plus 828 E H Plus 828 E B
02-08-066
01 160928 pump, cpl. vp 5 3,44 xxxxxx
02 061707 de-aerator xxxxxx
03 118951 oval head screw M 6x28,5 xxxxxx
04 019383 connection tube, cpl. pump-interface 39,44,46 xxxxxx
05 019379 connection tube, cpl. interface-heat exchanger 34,39,44 x x x
019381 connection tube, cpl. interface-heat exchanger 34,39,44 x x x
06
019385 connection tube, cpl. 34,39,44,46 x x x
019387 connection tube, cpl. 34,39,44,46 x x x
022777 connection tube, cpl. 34,39,44,46 x x x
022778 connection tube, cpl. 34,39,44,46 x x x
07 252805 ntc-resistor, cpl. xxxxxx
08 256097 cable tree, cpl. xxxxxx
09
019391 connection tube, cpl. 35,39 xxxx
022784 connection tube, cpl. 35,39 xxxx
10 150240 automatic bypass valve, cpl. 35,39,42 xxxx
11a 019390 connection tube, cpl. 35,42 xxxx
11b
019389 connection tube, cpl. bypass tube 30,35,39,42 x x
022783 connection tube, cpl. bypass tube 30,35,39,42 x x
12 252457 diverter valve, cpl. 35,39,42 xxxxxx
13 140429 motor, cpl. diverter valve xxxxxx
14
065088 secondary heat exchanger, cpl. 12 35,37,42 xxxxxx
065107 secondary heat exchanger, cpl. 12 35,37,42 xxxxxx
15
081162 connection tube W-W, cpl. 35,37 xxxxxx
022776 connection tube w-w, cpl. 35,37 xxxxxx
16 194819 impeller, cpl. aqua sensor 33,35,42,43 xxxxxx
17 014692 pressure relief valve 38 xxxx
18 711933 sensor cpl. hall-sensor xxxxxx
19 014675 valve, cpl. filling without non-return valve 20,33,38,43 xxxx
19a 139471 plug 43 xxxxxx
20 125151 handle fill-in valve xxxxxx
21a 019376 connection tube, cpl. fill-in device GB 41.43 xxxx
21b 014676 valve, cpl. doublecheck 41 xxxx
21c 095610 hose, cpl. 38.41 xxxx
22
019388 connection tube, cpl. 35,42,44 xxxxxx
022782 connection tube, cpl. 35,42,44 xxxxxx
23 019377 connection tube, cpl. 33,35,43,44 xxxxxx
24 190732 safety valve, cpl. 35,42 xxxxxx
26 101271 manometer 27,45 xxxxxx
27 085751 support xxxxxx
28 019372 connection tube, cpl. 36,40,41 xxxxxx
29 181057 expansion vessel cpl. 10 ltr.
x
x
x
x
x
x
x xxxxx
TURBOma
x
Pos.-
No.
Article-No. Part
25 019392 connection piece, cpl. pump
with parts
3,27,30,32,35,36,
41,42,44,45
Only for versions below ../2 e.g. VUW 242
Only for ../2 versions e.g. VUW 242/2
Only for versions below ../2 e.g. VUW 242
Only for ../2 versions e.g. VUW 242/2
Only for versions below ../2 e.g. VUW 242
Only for ../2 versions e.g. VUW 242/2
Only for versions below ../2 e.g. VUW 242
Only for ../2 versions e.g. VUW 242/2
Only for versions below ../2 e.g. VUW 242
Only for versions below ../2 e.g. VUW 242
Only for ../2 versions e.g. VUW 242/2
Only for ../2 versions e.g. VUW 242/2
Subject to alteration ! 802762.04 GB 05/01
