Main component 08a Hydraulic parts
THERMOcompact VU 152 -5, 202 -5, 242 -5, 282 -5 H/B (inc. ../2)
615 E H 620 E H 620 E B 624 E H 628 E H 628 E B
02-08-080
01 160928 pump, cpl. vp 5 3,44 xxxxxx
02 061707 de-aerator xxxxxx
03 118951 oval head screw M 6x28,5 xxxxxx
04 019383 connection tube, cpl. pump-interface 39,44,46 xxxxxx
05 019379 connection tube, cpl. interface-heat exchanger 34,39,44 xxxx
019381 connection tube, cpl. interface-heat exchanger 34,39,44 x x
06
019385 connection tube, cpl. 34,39,44,46 xxxx
019387 connection tube, cpl. 34,39,44,46 x x
022777 connection tube, cpl. 34,39,44,46 xxxx
022778 connection tube, cpl. 34,39,44,46 x x
07 252805 ntc-resistor, cpl. xxxxxx
09
019391 connection tube, cpl. 35,39 xxxxxx
022784 connection tube, cpl. 35,39 xxxxxx
10 150240 automatic bypass valve, cpl. 35,39,42 xxxxxx
11 019390 connection tube, cpl. 35,42 xxxxxx
14 084984 connection piece 39 xxxxxx
18 109926 cap, cpl. 44 xxxxxx
19 139471 plug 43 xxxxxx
23 019377 connection tube, cpl. 33,35,43,44 xxxxxx
24 190732 safety valve, cpl. 35,42 xxxxxx
26 101271 manometer 27,45 xxxxxx
27 085751 support xxxxxx
28 019372 connection tube, cpl. 36,40,41 xxxxxx
29 181057 expansion vessel cpl. 10 ltr. xxxxxx
32 118937 oval head screw M5x12 xxxxxx
33 154150 bow xxxxxx
34 219621 clip primary heat ex., set of 6 xxxxxx
35 219622 clip, set of 10 xxxxxx
36 219623 clip, set of 10 xxxxxx
38 981146 washer 5,5x11,0x1,5, set of 10 xxxxxx
39 981140 washer 17,0x24,0x2,0, set of 10 xxxxxx
40 981149 washer 10,0x14,9x1,5, set of 10 xxxxxx
41 981165 packing ring 12,0x2,0, set of 10 xxxxxx
42 981163 packing ring 15,0x2,0, set of 10 xxxxxx
43 980305 packing ring 9,0x2,0 xxxxxx
44 981151 packing ring 19,0x3,15, set of 10 xxxxxx
45 981155 packing ring 4,0x1,4, set of 10 xxxxxx
46 980765 packing ring, red, large xxxxxx
25 019392 connection piece, cpl. pump
with parts
Pos.-
No.
Article-No. Part
Only for versions below ../2 e.g. VUW 242
Only for ../2 versions e.g. VUW 242/2
THERMOcompac
t
xxxxxx
Only for versions below ../2 e.g. VUW 242
Only for ../2 versions e.g. VUW 242/2
3,27,30,32,35,36,
41,42,44,45
Subject to alteration ! 802762.04 GB 05/01
