Main component 12 Switch box
TURBOmax Pro/Plus VUW 242 -3, 282 -3, 242 -5, 282 -5 H/B (inc. ../2)
THERMOcompact VU 152 -5, 202 -5, 242 -5, 282 -5 H/B (inc. ../2)
Pro 24 E H Pro 28 E H Plus 824 E H Plus 824 E B Plus 828 E H Plus 828 E B 615 E H 620 E H 620 E B 624 E H 628 E H 628 E B
02-12-029
01 136894 switch front, cpl. xxxxxx xxxxxx
02 088734 lock xxxxxx xxxxxx
03 - not available
04 136882 switch back, cpl. xxxxxx xxxxxx
05 114286 knob, cpl. (3 knobs + lever) xxxxxx xxxxxx
06 077954 cover, cpl. display xxxx xxxxxx
07 257957 control switch x x
08 132925 plug, set of 10 xxxxxx xxxxxx
09 101271 manometer xxxxxx xxxxxx
10 287450 transformer, cpl. xxxxxx xxxxxx
11 130473 printed circuit, cpl. x x
130474 printed circuit, cpl. xxxx xxxxxx
12 256097 cable tree, cpl. xxxxxx
256116 cable tree, cpl. xxxxxx
13 219629 clip control box, set of 5 xxxxxx xxxxxx
14 077958 covering plate x x
15 - not for GB
251921 fuse (1.25 Amp) not shown xxxxxx xxxxxx
130037 fuse (2.0 Amp) not shown xxxxxx xxxxxx
THERMOcompac
t
with parts
TURBOma
x
Pos.-
No.
Article-No. Part
Subject to alteration ! 802762.04 GB 05/01
