4.16.4 Connection details for programmable thermostats
Fig. 4.20
LN
234
LN 3
4
1
ACL Drayton
Lyfestyle PT271, PT371
ACL Drayton
Digistat 2, 3, 4
ACL Drayton
Digistat RF - SCR Receiver
Danfoss Randall
TP4, TP5, TP5E
Danfoss Randall
TP5E RF with receiver RX1
Danfoss Randall
TP75
Grässlin Towerchron
RTC7
Honeywell
CM61, CM67, CM31, CM37
Horstmann
Centaurstat 1, 7
Landis & Staefa
REV 11, REV 15, REV 22
12
34
3
Sunvic
TLX 6501
Sunvic
TLX RFP, TLX RFD
Vaillant
VRT 230, 220
N1
3
N3
2
L
L
4
32
43
1
LN
234
LN 3
4
1
BC
2341
A
3
56
4
12
34
3
AB
34
C
12
4
34
3
LL1
34
Smiths Timeguard
ProgramaSTAT PRT11, PRT17
LN
4
LN
3
34
12
34
3
LN
234
LN 3
4
1
34
34
5
5
4.17 Controls (ecoMAX 800)
4.17.1 External electrical controls
The boiler terminals 3, 4 and 5 are for connecting exter-
nal electrical controls such as a time switch and/or room
thermostat. Terminals 3 and 4 are linked together when
the boiler is supplied. If external controls are used, this
link must be removed, and the controls connected
across terminals 3 and 4. Terminal 5 is an additional
neutral connection for external neutrals such as from
the anticipator of a room thermostat.
4.17.2 Connection of external controls
4.17.3 Connection details for programmable room
thermostats
Fig. 4.19 shows the connection details where a pro-
grammable room thermostat (time switch with built in
room thermostat) is used to control the boiler.
Important:
The arrowed numbers indicate connection into
the relevant terminal in the boiler terminal strip.
